direct shear apparatus (manually)

Name: direct shear apparatus (manually)
Brand: V.K.SCIENTIFIC INSTRUMENTS
Price: 80000 INR
Availability: InStock

80000 INR/Set

Get a Price/Quote

Product Details:

Port Size Standard 10 mm diameter (for dial gauge fitting)
Specimen Size 60 mm x 60 mm x 25 mm
Frequency Not applicable (manual)
Power Supply Not required (Hand operated)
Response Time Instantaneous (manual control)
Resolution 0.01 mm (displacement)
Max Height Approx 300 mm (without weights)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

direct shear apparatus (manually) Price And Quantity

Price 80000 INR/Set
Minimum Order Quantity 1 Set

direct shear apparatus (manually) Product Specifications

Automation Grade Manual
Application Determination of the shear strength parameters of soil
Features Rigid frame, smooth operation, corrosion resistant components, easy weight placement
Machine Weight Approximately 55 kg
Interface Type Mechanical dial indicator
Number of Specimens Single specimen per test
Equipment Type Manual Direct Shear Apparatus
Test Range 0-200 kN/m2 (with supplied weights and proving ring)
Measuring Range 0-800 N (using proving ring)
Operating Voltage Not applicable (manual hand-operated)
Test Speed Adjustable; typical rate: 1.25 mm/min
Temperature Ambient (5C - 40C)
Test Width 60 mm
Display Type Analog (dial gauge)
Control Mode Manual
Frequency Not applicable (manual)
Usage Laboratory geotechnical testing
Power Supply Not required (Hand operated)
Capacity 8 kg (normal loading)
Response Time Instantaneous (manual control)
Specimen Size 60 mm x 60 mm x 25 mm
Port Size Standard 10 mm diameter (for dial gauge fitting)
Test Stroke Up to 10 mm
Resolution 0.01 mm (displacement)
Humidity Ambient laboratory conditions (not humidity controlled)
Max Height Approx 300 mm (without weights)
Accuracy 1% of reading
Hardness Hardened steel components at contact points
Mounting Type Bench top

Displacement Measurement Horizontal and vertical dial gauges
Shear Box Size 60 mm x 60 mm square with removable upper and lower parts
Sample Preparation Tools Supplied with soil sample former and tamper
Lateral Movement Horizontal movement via precision screw jack
Max Load Capacity Up to 8 kg normal load
Shear Rate Options Step-wise variable (by manual control)
Safety Features Lockable positioning screws, non-slip base
Shear Force Measurement Via 2 kN capacity proving ring
Material of Construction Mild steel frame with stainless steel shear box
Accessories Included Set of weights, two dial gauges, one proving ring, shear box with grid plates & porous stones
Normal Force Measurement Calibrated lever arm with weight hanger
Loading Mechanism Dead weight lever loading system
Dial Gauge Least Count 0.01 mm
Corrosion Protection Powder coated and plated parts

direct shear apparatus (manually) Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 10 Set Per Month
Delivery Time 5-7 Days
Main Domestic Market All India

Product Description

Experience the acclaimed and classic engineering precision with this manual Direct Shear Apparatus, a must-have tool for geotechnical laboratories. Precision-crafted with a valiant mild steel frame and stainless steel shear box, its design accommodates a 60 mm x 60 mm square specimen for reliable soil shear strength testing. The virtuoso setup features a dead weight lever loading system, removable parts, and corrosion protection, elevating accuracy and durability. Accessories such as dial gauges and proving ring enhance its value, while safety locking and non-slip base provide secure, effortless operation. A proven performer for robust geotechnical analysis.

Versatile Testing Solution for Soil Mechanics Laboratories

The manual direct shear apparatus is purpose-built for precise measurement of soil shear strength parameters. Ideal for academic institutions, research laboratories, and commercial construction companies, it is extensively used in foundation analysis, slope stability evaluation, and pavement design. Its robust configuration ensures consistent results for a variety of soil types, making it indispensable for geotechnical engineering investigations and quality control in civil infrastructure projects.

Efficient Sample Policy and Global Logistics Network

Our sample policy ensures you can assess the apparatus quality before large orders. With stock ready for dispatch, we guarantee swift shipment and streamlined logistics, handling orders efficiently for a wide clientele. The FOB port is conveniently located in India, and we cater to main export markets including Asia, Africa, and the Middle East. Each apparatus is shipped securely packed, making international delivery reliable and stress-free for our valued customers.

FAQ's of direct shear apparatus (manually):

Q: How does the manual direct shear apparatus measure shear strength in soil samples?

A: The manual direct shear apparatus measures shear strength by applying a variable load using a dead weight lever system while shearing a soil sample in the precision shear box. The resulting horizontal displacement and load are tracked via proving ring and dial gauges, providing accurate shear parameters.

Q: What are the main benefits of using this apparatus in geotechnical testing laboratories?

A: The key benefits include high accuracy (1% of reading), durable mild steel and stainless steel construction for longevity, ease of manual operation without power supply, and corrosion-resistant design. These features ensure reliable, repeatable results and simple maintenance.

Q: Where is this apparatus primarily used?

A: This direct shear apparatus is used in soil mechanics and geotechnical engineering laboratories, educational institutions, construction quality control settings, and research facilities requiring soil strength determination.

Q: When should the apparatus be recalibrated for precision results?

A: It is recommended to recalibrate the apparatus at the beginning of each major testing cycle or after significant use, especially if transported, to maintain measurement accuracy and consistency.

Q: What is included with each unit for immediate testing?

A: Each apparatus is supplied with a full accessory kit: set of weights, two dial gauges, one 2 kN proving ring, removable shear box, grid plates, porous stones, sample former, and tamper for preparing different soil samples.
