Soil Testing CBR Machine

Name: Soil Testing CBR Machine
Brand: V.K.SCIENTIFIC INSTRUMENTS
Price: 50000 INR
Availability: InStock

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Soil Testing CBR Machine Specification

Application
Determination of California Bearing Ratio (CBR) of soil

Display Type
Analog or Digital Force Gauge

Mounting Type
Table top

Max Height
Approx. 1.0 meter

Resolution
0.01 kN

Frequency
50 Hz

Hardness
Heavy-duty steel construction

Specimen Size
150 mm diameter x 175 mm height (standard)

Interface Type
Mechanical dial / digital display (model-dependent)

Operating Voltage
220-240 V

Humidity
Up to 95% RH, non-condensing

Accuracy
1%

Automation Grade
Manual / Semi-automatic

Temperature
5C to 40C

Port Size
Standard 50 mm cylinder

Test Range
0-50 kN

Measuring Range
0-50 kN

Number of Specimens
Single specimen at a time

Response Time
Instantaneous

Features
Hand operated with mechanical jack and calibrated dial gauge, optional motorized version

Power Supply
220-240 V AC, 50 Hz

Usage
Soil testing for CBR determination

Capacity
50 kN (5,000 kg)

Machine Weight
Approx. 90-120 kg

Test Speed
1.25 mm/min (Standard)

Test Width
50 mm - 70 mm

Test Stroke
Up to 100 mm

Control Mode
Manual with Mechanical Jack or Motorised with Electric Motor

Finish
Powder coated / Painted

Load Measuring Device
Proving ring with dial gauge or load cell with digital indicator

Packing
Export worthy wooden crate or box

Equipment Type
CBR Testing Machine

Travel Measurement
Dial gauge 0.01 mm least count

Plunger Size
50 mm diameter (standard, as per IS 2720 Part 16)

Safety Feature
Overload protection

Frame Type
Rigid, corrosion-resistant steel frame

Motor Power (if motorised)
0.5 HP single-phase motor

Accessories
Cutting collar, spacers, rammers, surcharge weights, annular/ slotted weights

Compliances
IS 2720 (Part XVI), ASTM D1883

Soil Testing CBR Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Soil Testing CBR Machine

Purchase a world-class Soil Testing CBR Machine designed for precise California Bearing Ratio (CBR) determination of soils. This radiant, durable equipment features a lofty rigid steel frame, available in manual and motorised models, and ensures robust performance with a proving ring or load cell for accurate load measurement. With overload protection and compliance to IS 2720 and ASTM D1883, every unit comes with essential accessories like cutting collars and spacers. Buy today - enjoy a powder-coated finish, export-worthy packaging, and exceptional testing accuracy for geotechnical labs, research, or field usage.

Application Media and Utilization Areas

The Soil Testing CBR Machine excels in engineering applications such as highway and railway design, real estate projects, and research laboratories. Its primary application media includes compacted soils and subgrade layers. This versatile machine is suitable for use in civil engineering consulting, educational institutions, soil investigation companies, and at on-site construction laboratories, guaranteeing reliable and reproducible CBR values essential for infrastructure development and ground improvement assessments.

Main Domestic Market and Order Processing

The Soil Testing CBR Machine is regularly supplied to buyers across India-a major domestic market for this equipment. With a secured FOB port, we dispatch orders efficiently in export-worthy packaging. Sale price and asking price are available upon request, and order processing is streamlined for bulk and individual needs. Samples are available for qualified buyers, ensuring customer satisfaction before purchase decisions, and our after-sales support underlines reliability and professionalism throughout the transaction process.

FAQ's of Soil Testing CBR Machine:

Q: How does the Soil Testing CBR Machine determine the California Bearing Ratio of soil?

A: The machine uses a plunger and proven load measuring device to apply controlled force to soil specimens, measuring resistance precisely to determine the California Bearing Ratio (CBR) as per IS 2720 Part 16 and ASTM D1883 standards.

Q: What are the key benefits of using a CBR Testing Machine in road construction?

A: Using a CBR Testing Machine helps engineers assess soil strength and compaction, ensuring reliable subgrades for highways and runways. This contributes directly to safer, longer-lasting roadways and optimized construction budgets.

Q: Where can this equipment be used?

A: The Soil Testing CBR Machine is ideal for laboratories, field locations at construction sites, research centers, and educational institutions engaged in soil investigations for infrastructure projects.

Q: When should soil be tested with a CBR Machine during a project cycle?

A: Soil testing with the CBR Machine is essential during the preliminary design phase and prior to construction in order to assess soil suitability and inform foundational decisions for transportation or structural projects.

Q: What is the process for ordering the CBR Testing Machine?

A: Interested customers can request sale price and ask for quotations. Orders are processed swiftly with provision for sample evaluation, and secure packing ensures the equipment reaches your site in optimal condition.
