Cylindrical Mould

Name: Cylindrical Mould
Brand: V.K.SCIENTIFIC INSTRUMENTS
Price: 2000 INR
Availability: InStock

Price 2000 INR/ Set

Get a Price/Quote

MOQ : 1 Set

Cylindrical Mould Specification

Max Height
300 mm or as per model

Humidity
Standard Ambient

Features
Rugged construction, corrosion resistant, split type with clamp, easy demoulding

Hardness
Above 50 HRC (body surface)

Automation Grade
Manual

Accuracy
High dimensional accuracy as per IS 10086 / ASTM C31

Specimen Size
150 mm diameter 300 mm height / 100 mm diameter 200 mm height (customizable)

Application
Compression Strength Test of Concrete Cylinders

Number of Specimens
1 per mould

Mounting Type
Free Standing/Manual placement

Temperature
Ambient

Equipment Type
Concrete Test Mould

Usage
Laboratory or field concrete testing

Capacity
1 Specimen per mould

Machine Weight
Approx. 4-6 kg (depending on size)

Control Mode
Manual

Material of Construction
Cast Iron / Mild Steel / Steel as per specification

Demoulding
Easy demoulding due to split design

Packing
Cardboard box or custom packing

Mould Parting
Split along vertical axis with fitting clamps

Color
Blue or as per customer preference

Shape
Cylindrical, Split Type

Reusability
Reusable for multiple test cycles

Surface Finish
Smooth, machined

Clamping Type
Fitted with base plate and threaded rods

Cylindrical Mould Trade Information

Minimum Order Quantity
1 Set

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Sets Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Cylindrical Mould

A cylindrical mould is specialized type of mould primarily used in civil engineering and construction laboratories to prepare cylindrical concrete specimens.

Details and feature

Purpose: It is used to cast specimens for testing the compressive strength , split tensile strength , and mouluds of elasticity of concrete.

Design: it is typically divided into two vertical section (split type) thet are fastened together using clamps or bolts. This allows the specimen to be easily removed (demoulded) without damage after the concrete has set.

Material: it is made from heavy cast iron, mild steel ,or high quality plastic/polyurethane.

Base: it comes with a detachable, flat base plate that prevents leakage during concrete pouring

standards size: 150x300mm, 150x200mm

FAQ's of Cylindrical Mould:

Q: How is the demoulding process facilitated with the Cylindrical Mould?

A: The Cylindrical Mould features a split design fitted with clamps, allowing easy demoulding after concrete has set. Simply loosen the clamps and remove the specimen smoothly without damaging the sample.

Q: What materials are used in constructing the Cylindrical Mould?

A: The mould is constructed from high-quality cast iron, mild steel, or steel, offering excellent durability, hardness above 50 HRC, and corrosion resistance for repeated laboratory or field use.

Q: When should I use the Cylindrical Mould in my testing workflow?

A: Use the Cylindrical Mould whenever you need to prepare concrete specimens for compression strength testing, especially in compliance with IS 10086 or ASTM C31 standards.

Q: Where can the Cylindrical Mould be applied?

A: This mould is suitable for use in laboratories, construction sites, and field testing scenarios where precise concrete cylinder samples are required for strength evaluation.

Q: What are the main benefits of using this mould for compression tests?

A: Key benefits include high dimensional accuracy, rugged and reusable construction, easy demoulding process, and customization options to fit standard and non-standard specimen sizes.
