porctor compaction test apparatus

Name: porctor compaction test apparatus
Brand: V.K.SCIENTIFIC INSTRUMENTS
Price: 65000 INR
Availability: InStock

65000 INR/Set

Get a Price/Quote

Product Details:

Specimen Size 100 mm or 150 mm diameter; 127.3 mm and 127.3 mm height respectively
Accuracy Corresponds to IS:2720 (Part VII & VIII); ASTM D698/D1557 standards
Humidity Within lab environment, maximum 80% RH non-condensing
Display Type None; manual reading
Temperature Testing at 15C-35C (room temperature)
Number of Specimens One specimen per mould per test
Power Supply Not Required (Manual)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

porctor compaction test apparatus Price And Quantity

Price 65000 INR/Set
Minimum Order Quantity 1 Set

porctor compaction test apparatus Product Specifications

Application Soil Compaction Testing in Civil Engineering
Port Size Mould inner diameter: 100 mm or 150 mm
Equipment Type Compaction Test Apparatus
Response Time Immediate upon compaction
Control Mode Manual hammer compaction
Measuring Range Lab compaction of soils for density/moisture determination
Max Height Approx. 400 mm including hammer in raised position
Mounting Type Tabletop
Test Range Dry density vs. moisture content curve
Resolution Depends on external scale and balance used
Usage Soil laboratory testing, educational & field quality control
Test Stroke Hammer drop height: 310 mm (Standard), 450 mm (Modified)
Automation Grade Manual
Number of Specimens One specimen per mould per test
Power Supply Not Required (Manual)
Features Includes ISI marked compaction mould, base plate, collar, hammer
Hardness High-grade steel for hammer and mould
Interface Type Manual operation
Temperature Testing at 15C-35C (room temperature)
Display Type None; manual reading
Humidity Within lab environment, maximum 80% RH non-condensing
Test Speed Manual operation
Test Width Standard mould diameter: 100 mm or 150 mm
Specimen Size 100 mm or 150 mm diameter; 127.3 mm and 127.3 mm height respectively
Capacity Standard Proctor: 2.6 kg hammer; Modified Proctor: 4.9 kg hammer
Accuracy Corresponds to IS:2720 (Part VII & VIII); ASTM D698/D1557 standards
Machine Weight Approx. 7-10 kg (including mould and accessories)

Base Plate Detachable, machined, corrosion-resistant
Hammer Type Removable, guide sleeve ensuring free and vertical drop
Mould Material Machined mild steel with chrome-plated finish
Safety Pin lock mechanism for secure operation
Collar Height 50 mm (Standard), steel
Transportability Portable with easy disassembly
Service Life Designed for long-term repetitive laboratory use
Accessories Included Mould, collar, base plate, hammer, manual, spanner
Hammer Material Mild steel with lock nut and guide sleeve
Standard Compliances IS: 2720 (Part 7 & 8), ASTM D698, ASTM D1557, BS 1377
Mould Capacity 1000 ml (Standard), 2250 ml (Large/Modified)
Finish Powder-coated for corrosion resistance

porctor compaction test apparatus Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 10 Set Per Month
Delivery Time 5-7 Days
Main Domestic Market All India

Product Description

Access masterful soil compaction testing with the Dominant Proctor Compaction Test Apparatus, crafted from enviable machined mild steel and finished with corrosion-resistant chrome plating. This robust, portable apparatus features a manually operated, removable hammer with a lock nut and smooth guide sleeve for consistent performance. Compliant with IS: 2720, ASTM D698, ASTM D1557, and BS 1377 standards, this apparatus empowers users to explore accurate dry density and moisture content correlations. Enjoy reliable operation, long service life, secure pin lock safety, and a discounted rate from India's leading exporter, manufacturer, and supplier.

Versatile Applications and User Suitability

The Proctor Compaction Test Apparatus is designed for use in soil laboratory testing, educational institutes, and field quality control in civil engineering projects. Suitable for laboratory and onsite testing, its manual operation and portable design ensure easy use for specialists, technicians, and educators requiring precision in determining soil density and moisture content relationships. This equipment is ideal for reliable soil compaction assessments, making it a staple for construction quality assurance and academic study.

Certifications, Supply, and Market Coverage

Our apparatus strictly complies with IS: 2720 (Part 7 & 8), ASTM D698, ASTM D1557, and BS 1377, ensuring accurate and credible results. Backed by reliable supply ability and timely packing & dispatch services, we proudly serve the main domestic market across India at the lowest price. Expect secure delivery and well-packaged equipment tailored to industry requirements, making our Proctor Compaction Test Apparatus a preferred choice among professionals nationwide.

FAQ's of porctor compaction test apparatus:

Q: How does the Proctor Compaction Test Apparatus assist in soil testing?

A: The apparatus allows users to determine the optimal moisture content and maximum dry density of soil, crucial for engineering projects requiring stable and compact ground.

Q: What are the standard compliances for this compaction test apparatus?

A: It complies with IS: 2720 (Part 7 & 8), ASTM D698, ASTM D1557, and BS 1377, meeting prominent global soil compaction testing criteria.

Q: When should this apparatus be used in construction or laboratory settings?

A: It is best used during preliminary site investigations, quality control phases of construction projects, and academic research involving soil compaction characteristics.

Q: Where can the apparatus be transported and operated conveniently?

A: Thanks to its portable design and easy disassembly, it can be used in laboratories as well as at field locations, making it versatile for various work environments.

Q: What is the process for conducting a compaction test with this equipment?

A: Prepare the soil sample, fill the mould, compact in layers using the manual hammer, and measure the resulting dry density and moisture content using external scales.

Q: What benefits do users gain from this apparatus?

A: Users access durable, accurate, and standard-compliant equipment that ensures consistent, repeatable test results for better construction quality control and academic research.
